Anti-Corrosion Metallic Copper Gold Powder Coating Paint

Quantity:
  • EP-DY
  • Metal
  • Film Forming Matter
  • Antiseptic Paint
  • Conversion Type
  • 120-150%
  • 60-80um
  • 2h
  • 0 Grade
  • 50kg/Cm
  • WONDER
  • 20kg/CTN
  • 39.5*30*35
  • Guangdong, China
  • 3907999990
Specification
Anti-Corrosion Metallic Copper Gold Powder Coating Paint
Product Details
Type Anti-Corrosion Metallic Copper Gold Powder Coating Paint
Color Copper Gold
Surface Finish Smooth
Gloss level 120-150%
Particle Size Average 32-42μm
Specific Gravity 1.2-1.7g per cubic meter
Coverage 8-10 square meters per Kg at 30-90 μm film thickness
film thickness Two Layers 120-150um
Application Recommendation
Application Voltage 40-60 KV
Gun to Component Distance 15-30CM
Curing Temperature 200ºC x 10min
Powder coated Film Mechanical Properties
Adhesion Cross-cut(2mm),no loss of adhesion
Impact Resistance Direct impact 50kg/cm
Pencil Hardness 2H
Cupping Test 6mm Mandrel
Bending Test 5mm
Powder Coated Film Chemical Resistance
Salt Spray Test 5% NaCl Solution for 500 hours - No change
Acid Resistance 5% HCL for 48 hours dip test - No change
Alkali Resistance 5% NaOH for 48 hours dip test - No change
Storage Stability
Store in ventilated, dry, clean room, temperature < 25ºC
Relative humidity 50-65%
Away from direct sunlight, fire, heat
For best performance, use within 6 months

Anti-Corrosion Metallic Copper Gold Powder Coating Paint
Anti-Corrosion Metallic Copper Gold Powder Coating Paint
1. Production workshop set up in 1989, leading powder coating supplier with rich experience in China.
2. Four factories in total. Three are Powder Coating Production Base, one is Nano-Dryplating Spraying Base.
3. 16 Production Lines. 5 Bonding Lines. 9 Sample Lines.
4. Annual Capacity reaches 10,000 Tons.
5. Nano-Dryplating Silver Chrome Effect Powder Coating is identified as Guangdong High-Tech Product.
6. Oversea Countries: Sweden, America, Turkey, Russia, Guatemala, Peru, Pakistan, UAE, Vietnam, Sri Lanka, etc,
7. Native Cooperative Clients: MEDIA, GREE, KELON, DAYANG.

Anti-Corrosion Metallic Copper Gold Powder Coating Paint

Anti-Corrosion Metallic Copper Gold Powder Coating Paint


Anti-Corrosion Metallic Copper Gold Powder Coating Paint
Q1. Can I have a sample order for powder coating?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?
A: Sample needs 3-5 days, mass production time needs 1-2 weeks for inspection and customs declaration.

Q3. Do you have any MOQ limit for powder coating?
A: Low MOQ, 1-2kg sample powder checking is available.


Q4. How to proceed an order for powder coating?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.


Q5: Do you offer guarantee for the products?
A: Yes, we offer professional after-sale service for every customer.
