Electrostatic Spray Polyester Light Grey Ral 7035 Powder Coating

Quantity:
  • EP-RAL, PT-RAL

  • Steel

  • Film Forming Matter

  • Antiseptic Paint

  • Conversion Type

  • Electrostatic Spray Polyester Light Grey Ral 7035

  • High/Semi/Matte

  • 60-80um

  • 0 Grade

  • 2h

  • 12 Months

  • 180 Degree/15mins, 200 Degree/10mins

  • High Voltage Electrostatic Spraying 40-80kv

  • at About 25 Degree and at Ventilated Indoors

  • Lined in with Double PE Bags. Packed in Carton Box

  • Wonder

  • 25kg/CTN

  • carton size: 39.5cm*30cm*35cm.

  • China

  • 3907999990

Product Name: electrostatic spray polyester light grey Ral 7035 powder coating

Description of Product

Powder coatings are mixed with a certain proportion of the resin, fillers, curing agents and other additives, then prepared by hot extrusion ,crushed and sieved. The products are stable at room temperature storage, then baking heat melted and solidified to form a smooth and bright permanent coating to achieve the purpose of decoration and corrosion.
It is suitable for metal/ iron/ aluminum surface of each indoor product such as furniture, electrical appliance, industrial equipment, sports equipment, hardware, shop tool rack and lamps and lanterns etc.
Color Grey Color
Type Epoxy Polyester Indoor
Gloss 30-50%
Thickness 60-80μm
Hardness 2H
Adhesion 0 Grade
Curing 200ºC*10mins / 180ºC*15mins
Shelf Life 12 months

Different Types of Product

1.Chrome Nano-dryplating It has applied for national patent. It meets the most strict environment demands and excellent physics and chemical properties, while the cost is much lower than electroplating. With chrome effect powder coating. (NEW AND HOT)
2.RAL Powder Coatings
3.Epoxy-polyester Powder Coatings
4.Polyester Powder Coatings (TGIC/Primid)
5.Texture Wrinkle Powder Coatings
6.Metallic Powder Coatings
7.Electrostatic Powder Coatings
8.Chrome effect Powder Coatings, etc.

Product Test
Item Instrument Standard Testing Result
Pencil hardness Pencil hardness instrument ≥ H 2H
Impact resistance Impact tester ≥ 30 kg.cm 30 kg.cm
Flexing endurance Bending instrument ≤ 2mm No cracks nor stripping
Adhesive force Cross-Cut tester 0 grade 0 grade
Bulge Bulge instrument ≥ 6 mm Pass
Resistance to salt spray ≥ 500 Hs ≥ 9 grade Pass
Resistance to heat and humidity ≥ 1000 Hs Slight loss of gloss Pass

Storage condition: at about 25ºC and at ventilated indoors, avoiding direct sunlight. Under such condition, powder can be stored for twelve months and should be re-tested if more than twelve months.

Pre-sale Notice &services
1.Curing conditions:
Oven Temperature Heating Time
200°C 10min
180°C 15min
160°C 20min
2.Surface appearance:
metallic effect (Gold, silver) , chrome candy effect (Red, Blue, Green, Purple…), smooth effect, art textures effect (sand, wrinkle) ect.
3.Gloss level:
High gloss 50%-90%
Semi gloss 7%-50%
Matt gloss below 7%
Chrome Silver gloss 450 - 600%
Chrome Candy Type gloss 90 - 150%

Trade Items of Product
MOQ 200KG
Pakage Box with PE plastic bag
Delivery Term FOB, CFR, CIF,EXW,Express delivery
Delivery Time 15 days after pay us deposit
Payment Term T/T
Supply Ability 1000 Tons/Month
Port Jiangmen / Shenzhen / Guangzhou

Company Information
1).Production workshop set up in 1989, leading powder coating supplier with rich experience in China.
2). 4 Factories in total. Three are Powder Coating Production Bases, one is Nano-Dryplating Spraying Base.
16 Production Lines. 5 Bonding Lines. 9 Sample Lines.
Annual Capacity reaches 10,000 Tons.
3). Nano-Dryplating Silver Chrome Effect Powder Coating is identified as Guangdong High-Tech Product.
4). Oversea Countries: Sweden, Turkey, Russia, Guatemala, Peru, Pakistan, UAE, etc.

Why Choose Us:
Advantages we have:
A. Experienced state products supplier;
B. Professional design team and sales department for your service;
C. Factory recognized by EN71/ ROHS/ ISO9001 and so on.
D. 7/24 services for you, all the question will be dealed within 24 hours.

Benefit you get:
A. Stable quality -- Coming from good materials and technic
B. Lower price -- Not cheapest but the lowest at the same quality
C. Good service -- Satisfactory service before and after sale
D. Delivery time -- 10-15 days for mass production

How to Order Our Product
Customers offer general information of the product.
Our technician will make a professional suggestion according to your need.
After your confirmation, we will send samples to you for evaluation.
Note: Customers can order all product samples we put or you can also have your own idea, as we are custom-made product supplier, so different colors and types are available.

FAQ
Q1. Can I have a sample order for powder coating?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?
A: Sample needs 3-5 days, mass production time needs 1-2 weeks for inspection and customs declaration.

Q3. Do you have any MOQ limit for powder coating?
A: Low MOQ, 1-2kg sample powder checking is available.

Q4. How to proceed an order for powder coating?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.

Q5: Do you offer guarantee for the products?
A: Yes, we offer professional after-sale service for every customer.
