EP-DY101766A
Metal
Film Forming Matter
Antiseptic Paint
Conversion Type
High Gloss
60-80um
2h
0 Grade
WONDER
25kg/CTN
39.5*30*35
Guangdong, China
3907999990
Color | Copper Gold |
Type | Epoxy Polyester |
Gloss | 80-90% |
Thickness | 60-80μm |
Hardness | 2H |
Adhesion | 0 Grade |
Curing | 200ºC*10min |
Shelf Life | 1 Year |
Test Item | Test Standard | Test Index |
Impact Resistance | GB/T 1732 -1993 | 50kg·cm |
Adhesion(Cross-Cut) | GB/T 9286 - 1998 | Class 0 |
Flexibility | GB/T 6742-1986 | 2mm |
Pencil Hardness | GB/T 6739-1996 | 1H-2H |
Salt Spray Test | GB/T 1771-1991 | >500 Hours |
Heat & Humidity Resistance | GB/T 1740-1979 | >500 Hours,film gloss slightly lose |
Gloss | 1. high gloss(above 80%), semi gloss(40-79%), matt gloss(5-39%) and no gloss(below 10°) 2. Gloss and texture can be customized as clients require |
Curing Condition | 1. Standard curing (200ºC×10min) 2. Lower temperature curing (180ºC×15min) |
Color | 1. RAL & Pantone Colors are available 2. Colors can be customized as clients require |
Standard | Special standards of product are available according to clients' requirements, e.g.RoHS standard, EN-71, FDA, LFGB, etc. |
Property | Excellent physical performance in hardness, flexibility and adhesion.. Good mechanical properties, outstanding heat resistance, fine corrosion, weather and chemical resistance. |
Storage | 1. The product can be stably stored for at least half year when kept in closed containers in a dry place at temperature below 25°C. 2. Keep it away from fire, heat and direct sunlight. 3. Avoid rains and exposure to sunshine during shipment. |
