Ral7032 Grey Texture Wrinkle Epoxy Powder Coatings for Electric Cabinet

Quantity:
  • ral7032
  • Steel
  • Film Forming Matter
  • Antiseptic Paint
  • Conversion Type
  • Ral7032 Grey Texture Wrinkle Epoxy Powder Coatings
  • High/Semi/Matte
  • 60-80um
  • 0 Grade
  • 2h
  • 12 Months
  • 180 Degree/15mins, 200 Degree/10mins
  • High Voltage Electrostatic Spraying 40-80kv
  • at About 25 Degree and at Ventilated Indoors
  • Lined in with Double PE Bags. Packed in Carton Box
  • Wonder
  • 25kg/CTN
  • carton size: 39.5cm*30cm*35cm.
  • China
  • 3907999990
Product Name: ral7032 grey texture wrinkle epoxy powder coatings for electric cabinet
Description of Product
Ral7032 Grey Texture Wrinkle Epoxy Powder Coatings for Electric Cabinet

Powder coatings are mixed with a certain proportion of the resin, fillers, curing agents and other additives, then prepared by hot extrusion ,crushed and sieved. The products are stable at room temperature storage, then baking heat melted and solidified to form a smooth and bright permanent coating to achieve the purpose of decoration and corrosion.

It is suitable for metal/ iron/ aluminum surface of each indoor product such as furniture, electrical appliance, industrial equipment, sports equipment, hardware, shop tool rack and lamps and lanterns etc.
Color Grey Color
Type Epoxy Polyester Indoor
Gloss 3-10%
Thickness 60-80μm
Hardness 2H
Adhesion 0 Grade
Curing 200ºC*10mins / 180ºC*15mins
Shelf Life 12 months


Product Test
Test Item Test Standard Testing Results
Specific Gravity ≤1.7 <1
Gloss 3 - 10% 9%
Thickness 60~80цm 77цm
Adhesive force GB/T9286-1998 0 grade
Impact Resistance GB/T1732-1993 30kg.cm no cracks nor stripping
Salt spray test GB/T1771-1991 500H,no pulverization,gloss protection 80%
Winding Resistance GB/T6742-1986 3mm no cracks nor stripping
Pencil Hardness GB/T6739-1996 2H
UV Resistance GB/T14522-1993 240h △E<1,gloss protection 80%
Flexibility GB/T 6742-1986 2mm
Heat & Humidity Resistance GB/T 1740-1979 >500 Hours,film gloss slightly lose


Company Information
1).Production workshop set up in 1989, leading powder coating supplier with rich experience in China.
2). 4 Factories in total. Three are Powder Coating Production Bases, one is Nano-Dryplating Spraying Base.
16 Production Lines. 5 Bonding Lines. 9 Sample Lines.
Annual Capacity reaches 10,000 Tons.
3). Nano-Dryplating Silver Chrome Effect Powder Coating is identified as Guangdong High-Tech Product.
4). Oversea Countries: Sweden, Turkey, Russia, Guatemala, Peru, Pakistan, UAE, etc.

Ral7032 Grey Texture Wrinkle Epoxy Powder Coatings for Electric Cabinet

How to Order Our Product
Customers offer general information of the product.
Our technician will make a professional suggestion according to your need.
After your confirmation, we will send samples to you for evaluation.
Note: Customers can order all product samples we put or you can also have your own idea, as we are custom-made product supplier, so different colors and types are available.

FAQ
Q1. Can I have a sample order for powder coating?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?
A: Sample needs 3-5 days, mass production time needs 1-2 weeks for inspection and customs declaration.

Q3. Do you have any MOQ limit for powder coating?
A: Low MOQ, 1-2kg sample powder checking is available.

Q4. How to proceed an order for powder coating?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.

Q5: Do you offer guarantee for the products?
A: Yes, we offer professional after-sale service for every customer.


Welcome to Contact Us
Ral7032 Grey Texture Wrinkle Epoxy Powder Coatings for Electric Cabinet
